MSP430F5526IYFFR
IC MCU 16BIT 96KB FLASH 64DSBGAManufacturer: Texas Instruments
Categories: Microcontrollers
Quality Control: Learn More
Texas Instruments MSP430F5xx series microcontroller, part number MSP430F5526IYFFR. This 16-bit device features the MSP430 CPUXV2 core running at 25MHz, with 96KB of FLASH program memory and 8KB of RAM. It includes a 12-bit Analog-to-Digital converter with 12 channels and integrates peripherals such as Brown-out Detect/Reset, DMA, POR, PWM, and WDT. Connectivity options include I2C, IrDA, LINbus, SCI, SPI, UART/USART, and USB. The device operates from a 1.8V to 3.6V supply and is packaged in a 64-DSBGA (64-UFBGA) for surface mounting. This component is suitable for applications in automotive, industrial, and consumer electronics. It is supplied on a Tape & Reel (TR) for automated assembly.
Additional Information
Series: MSP430F5xxRoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | 64-UFBGA, DSBGA |
| Mounting Type | Surface Mount |
| Speed | 25MHz |
| Program Memory Size | 96KB (96K x 8) |
| RAM Size | 8K x 8 |
| Operating Temperature | -40°C ~ 85°C (TA) |
| Oscillator Type | Internal |
| Program Memory Type | FLASH |
| EEPROM Size | - |
| Core Processor | MSP430 CPUXV2 |
| Data Converters | A/D 12x12b |
| Core Size | 16-Bit |
| Voltage - Supply (Vcc/Vdd) | 1.8V ~ 3.6V |
| Connectivity | I2C, IrDA, LINbus, SCI, SPI, UART/USART, USB |
| Peripherals | Brown-out Detect/Reset, DMA, POR, PWM, WDT |
| Supplier Device Package | 64-DSBGA |
| Number of I/O | 47 |
| Programmable | Not Verified |
