LM3S2965-IQC50-A2T
IC MCU 32BIT 256KB FLASH 100LQFPManufacturer: Texas Instruments
Categories: Microcontrollers
Quality Control: Learn More
Texas Instruments Stellaris® ARM® Cortex®-M3S 2000 series microcontroller, part number LM3S2965-IQC50-A2T, features a 32-Bit ARM® Cortex®-M3 core operating at 50MHz. This device offers 256KB of FLASH program memory and 64KB of RAM. Connectivity options include CANbus, I2C, IrDA, Microwire, QEI, SPI, SSI, and UART/USART. Integrated peripherals include Brown-out Detect/Reset, POR, PWM, and WDT. The component includes 4x10-bit analog-to-digital converters. Designed for surface mounting, it comes in a 100-LQFP (14x14) package. The operating temperature range is -40°C to 85°C (TA), with a supply voltage of 2.25V to 2.75V. This component is utilized in industrial automation, automotive, and consumer electronics applications.
Additional Information
Series: Stellaris® ARM® Cortex®-M3S 2000RoHS Status: ROHS3 CompliantManufacturer Lead Time: 18 week(s)Product Status: Not For New DesignsPackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | 100-LQFP |
| Mounting Type | Surface Mount |
| Speed | 50MHz |
| Program Memory Size | 256KB (256K x 8) |
| RAM Size | 64K x 8 |
| Operating Temperature | -40°C ~ 85°C (TA) |
| Oscillator Type | Internal |
| Program Memory Type | FLASH |
| EEPROM Size | - |
| Core Processor | ARM® Cortex®-M3 |
| Data Converters | A/D 4x10b |
| Core Size | 32-Bit Single-Core |
| Voltage - Supply (Vcc/Vdd) | 2.25V ~ 2.75V |
| Connectivity | CANbus, I2C, IrDA, Microwire, QEI, SPI, SSI, UART/USART |
| Peripherals | Brown-out Detect/Reset, POR, PWM, WDT |
| Supplier Device Package | 100-LQFP (14x14) |
| Number of I/O | 56 |
| Programmable | Verified |
