LM3S101-EGZ20-C2
IC MCU 32BIT 8KB FLASH 48VQFNManufacturer: Texas Instruments
Categories: Microcontrollers
Quality Control: Learn More
Texas Instruments LM3S101-EGZ20-C2 is a 32-bit ARM Cortex-M3 microcontroller from the Stellaris ARM Cortex-M3S 100 series. This single-core device operates at 20MHz and features 8KB of FLASH program memory with 2KB of RAM. Connectivity options include Microwire, SPI, SSI, and UART/USART. The LM3S101-EGZ20-C2 is housed in a 48-VQFN (7x7) package and supports a voltage range of 3V to 3.6V. Peripherals include Brown-out Detect/Reset, POR, PWM, and WDT. This component is suitable for applications in industrial automation, consumer electronics, and medical devices. It is available in Tray packaging with a surface mount type. The operating temperature range is -40°C to 105°C.
Additional Information
Series: Stellaris® ARM® Cortex®-M3S 100RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: DiscontinuedPackaging: TrayDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tray |
| Package / Case | 48-VFQFN Exposed Pad |
| Mounting Type | Surface Mount |
| Speed | 20MHz |
| Program Memory Size | 8KB (8K x 8) |
| RAM Size | 2K x 8 |
| Operating Temperature | -40°C ~ 105°C (TA) |
| Oscillator Type | Internal |
| Program Memory Type | FLASH |
| EEPROM Size | - |
| Core Processor | ARM® Cortex®-M3 |
| Data Converters | - |
| Core Size | 32-Bit Single-Core |
| Voltage - Supply (Vcc/Vdd) | 3V ~ 3.6V |
| Connectivity | Microwire, SPI, SSI, UART/USART |
| Peripherals | Brown-out Detect/Reset, POR, PWM, WDT |
| Supplier Device Package | 48-VQFN (7x7) |
| Number of I/O | 18 |
| Programmable | Not Verified |
