COP8CCR9LVA7/63SN
IC MCU 8BIT 32KB FLASH 68PLCCManufacturer: Texas Instruments
Categories: Microcontrollers
Quality Control: Learn More
Texas Instruments COP8CCR9LVA7-63SN is an 8-Bit COP8™ 8C microcontroller featuring 32KB of FLASH program memory and 1KB of RAM. This device operates at a speed of 20MHz and includes a comprehensive set of peripherals such as Brown-out Detect/Reset, Power-On Reset (POR), Pulse Width Modulation (PWM), and Watchdog Timer (WDT). Connectivity options include Microwire/Plus (SPI) and UART/USART interfaces. It is equipped with 16 analog-to-digital converters, each with a 10-bit resolution. The COP8CCR9LVA7-63SN offers 59 general-purpose I/O pins and operates within a voltage range of 2.7V to 5.5V. This component is housed in a 68-PLCC (24.23x24.23) surface-mount package and is supplied on tape and reel. Its robust feature set makes it suitable for applications in industrial automation, consumer electronics, and automotive systems.
Additional Information
Series: COP8™ 8CRoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Tape & Reel (TR)Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | 68-LCC (J-Lead) |
| Mounting Type | Surface Mount |
| Speed | 20MHz |
| Program Memory Size | 32KB (32K x 8) |
| RAM Size | 1K x 8 |
| Operating Temperature | -40°C ~ 125°C (TA) |
| Oscillator Type | Internal |
| Program Memory Type | FLASH |
| EEPROM Size | - |
| Core Processor | COP8 |
| Data Converters | A/D 16x10b |
| Core Size | 8-Bit |
| Voltage - Supply (Vcc/Vdd) | 2.7V ~ 5.5V |
| Connectivity | Microwire/Plus (SPI), UART/USART |
| Peripherals | Brown-out Detect/Reset, POR, PWM, WDT |
| Supplier Device Package | 68-PLCC (24.23x24.23) |
| Number of I/O | 59 |
| Programmable | Not Verified |
