MSP430F2274IYFF
RISC Microcontroller, 16-Bit, FLASH, 16MHz, Bipolar, PBGA49Manufacturer: Texas Instruments
Categories: Microcontrollers
Quality Control: Learn More
Texas Instruments MSP430 series 16-bit RISC microcontroller, part number MSP430F2274IYFF. This FLASH-based device operates at a maximum clock frequency of 16MHz and features 32 I/O lines. It includes integrated PWM channels and ADC channels, supporting applications requiring precise control and data acquisition. The microcontroller offers a wide operating temperature range from -40°C to 85°C and a supply voltage range of 2.2V to 3.6V, with additional operation at 1.8V minimum at 4.15 MHz. Packaged in a 49-terminal PBGA (JESD-30 Code: S-PBGA-B49) with a terminal pitch of 0.400mm, this surface-mount component is suited for industrial, automotive, and consumer electronics.
Additional Information
Series: MSP430RoHS Status: Manufacturer Lead Time: Product Status: DiscontinuedPackaging: Datasheet:Download Free CAD Model:
Technical Details:
| Speed | 16.00000000 |
| Technology | Bipolar |
| ADC_Channels | Yes |
| Additional_Feature | ALSO OPERATES AT 1.8 V MINIMUM SUPPLY AT 4.15 MHZ |
| Address_Bus_Width | 0 |
| Bit_Size | 16 |
| Clock_Frequency_Max | 16.0000000000000000 |
| DAC_Channels | No |
| DMA_Channels | No |
| External_Data_Bus_Width | 0 |
| JESD_30_Code | S-PBGA-B49 |
| Number_of_I_O_Lines | 32 |
| Number_of_Terminals | 49 |
| Operating_Temperature_Max | 85.0000 |
| Operating_Temperature_Min | -40.0000 |
| Package_Body_Material | PLASTIC/EPOXY |
| Package_Code | VFBGA |
| Package_Shape | Square |
| Package_Style | GRID ARRAY, VERY THIN PROFILE, FINE PITCH |
| Program_Memory_Type | FLASH |
| PWM_Channels | Yes |
| Seated_Height_Max | 0.6250 |
| Supply_Voltage_Max | 3.6000 |
| Supply_Voltage_Min | 2.2000 |
| Supply_Voltage_Nom | 2.7000 |
| Surface_Mount | Yes |
| Terminal_Form | Ball |
| Terminal_Pitch | 0.400 |
| Terminal_Position | Bottom |
| uPs_uCs_Peripheral_ICs_Type | MICROCONTROLLER, RISC |
