SN74LS601ADW3
Memory Controller, TTL, PDSO20Manufacturer: Texas Instruments
Categories: Memory Controllers
Quality Control: Learn More
The Texas Instruments SN74LS601ADW3 is a TTL-compatible memory controller designed for robust interfacing. This component, part of the SN74LS601 series, features a 20-terminal, rectangular, small outline plastic package (PDSO20) with a 1.270 mm terminal pitch and gull-wing terminal form. Operating within a temperature range of 0°C to 70°C, it supports a nominal supply voltage of 5.00V and exhibits a maximum supply current of 85mA. Its surface-mount capability and plastic/epoxy package material make it suitable for demanding applications. This device finds utility in industrial automation, telecommunications, and computing systems where precise memory management is critical.
Additional Information
Series: SN74LS601RoHS Status: Manufacturer Lead Time: Product Status: DiscontinuedPackaging: Datasheet:Download Free CAD Model:
Technical Details:
| Technology | TTL |
| JESD_30_Code | R-PDSO-G20 |
| Number_of_Terminals | 20 |
| Operating_Temperature_Max | 70.0000 |
| Operating_Temperature_Min | 0.0000 |
| Package_Body_Material | PLASTIC/EPOXY |
| Package_Code | SOP |
| Package_Equivalence_Code | SOP20,.4 |
| Package_Shape | Rectangular |
| Package_Style | SMALL OUTLINE |
| Supply_Current_Max | 85.00000000 |
| Supply_Voltage_Nom | 5.0000 |
| Surface_Mount | Yes |
| Terminal_Form | Gull Wing |
| Terminal_Pitch | 1.270 |
| Terminal_Position | Dual |
