TPS5300DAPRG4
IC REG TRP BCK/LNR SYNC 32HTSSOPManufacturer: Texas Instruments
Categories: Linear + Switching
Quality Control: Learn More
Texas Instruments TPS5300DAPRG4 is a versatile power management integrated circuit featuring a three-output architecture. This device integrates one synchronous step-down (buck) converter with two linear (LDO) regulators, providing flexible power solutions for complex designs. The TPS5300DAPRG4 is housed in a 32-HTSSOP package, suitable for surface mount applications. It supports an input voltage range of 3V to 28V, making it adaptable to a variety of power sources. This component is frequently utilized in automotive, industrial, and consumer electronics sectors where efficient and reliable voltage regulation is critical. The device is supplied in Tape & Reel packaging for automated assembly processes.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Tape & Reel (TR)Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | 32-PowerTSSOP (0.240"", 6.10mm Width) |
| Mounting Type | Surface Mount |
| Operating Temperature | 0°C ~ 125°C |
| Voltage - Supply | 3V ~ 28V |
| Frequency - Switching | - |
| Topology | Step-Down (Buck) Synchronous (1), Linear (LDO) (2) |
| Supplier Device Package | 32-HTSSOP |
| Voltage/Current - Output 1 | Controller |
| Voltage/Current - Output 2 | Controller |
| Voltage/Current - Output 3 | Controller |
| w/LED Driver | No |
| w/Supervisor | No |
| w/Sequencer | No |
| Number of Outputs | 3 |
