TPS7H1201SHKS
IC REG LIN POS ADJ 500MA 16CFPManufacturer: Texas Instruments
Categories: Linear, Low Drop Out (LDO) Regulators
Quality Control: Learn More
Texas Instruments TPS7H1201SHKS is a linear voltage regulator IC offering an adjustable positive output with a maximum output current of 500mA. This device features a low dropout voltage of 0.1V at 500mA, enabling efficient power delivery. The TPS7H1201SHKS includes robust control features such as current limit, enable, power good, and soft start for precise power management. Protection mechanisms include over current and over temperature shutdown. With a wide operating temperature range of -55°C to 210°C, this component is suitable for demanding applications. The Power Supply Rejection Ratio (PSRR) ranges from 45dB at 1kHz to 20dB at 100kHz. The adjustable output voltage can be set from 0.8V up to 6.8V, with a maximum input voltage of 7V. This device is housed in a 16-CFP (16-CFP) surface mount package. Its performance characteristics make it valuable in sectors such as aerospace, defense, and industrial automation.
Additional Information
Series: -RoHS Status: RoHS non-compliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: TrayDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tray |
| Package / Case | 16-CFlatpack |
| Output Type | Adjustable |
| Mounting Type | Surface Mount |
| Current - Output | 500mA |
| Operating Temperature | -55°C ~ 210°C |
| Output Configuration | Positive |
| Voltage - Input (Max) | 7V |
| Number of Regulators | 1 |
| Supplier Device Package | 16-CFP |
| Voltage - Output (Max) | 6.8V |
| Voltage - Output (Min/Fixed) | 0.8V |
| Control Features | Current Limit, Enable, Power Good, Soft Start |
| PSRR | 45dB ~ 20dB (1kHz ~ 100kHz) |
| Voltage Dropout (Max) | 0.1V @ 500mA |
| Protection Features | Over Current, Over Temperature |
