TPS7B8650BQDDARQ1
PROTOTYPEManufacturer: Texas Instruments
Categories: Linear, Low Drop Out (LDO) Regulators
Quality Control: Learn More
Linear Voltage Regulator IC Positive Fixed 1 Output 500mA 8-SO PowerPad
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: 6 week(s)Product Status: ActivePackaging: BulkDownload Free CAD Model:
Technical Details:
| Packaging | Bulk |
| Package / Case | 8-PowerSOIC (0.154"", 3.90mm Width) |
| Output Type | Fixed |
| Mounting Type | Surface Mount |
| Current - Output | 500mA |
| Operating Temperature | -40°C ~ 150°C (TJ) |
| Output Configuration | Positive |
| Current - Quiescent (Iq) | 26 µA |
| Voltage - Input (Max) | 40V |
| Number of Regulators | 1 |
| Supplier Device Package | 8-SO PowerPad |
| Voltage - Output (Max) | - |
| Voltage - Output (Min/Fixed) | 5V |
| Control Features | Delay, Enable, Power Good |
| Grade | Automotive |
| PSRR | 70dB (1kHz) |
| Voltage Dropout (Max) | 0.535V @ 500mA |
| Protection Features | Over Temperature, Under Voltage Lockout (UVLO) |
| Qualification | AEC-Q100 |
Request a Quote
