TPS73118DBVRG4
IC REG LINEAR 1.8V 150MA SOT23-5Manufacturer: Texas Instruments
Categories: Linear, Low Drop Out (LDO) Regulators
Quality Control: Learn More
Texas Instruments TPS73118DBVRG4 is a positive fixed output linear voltage regulator designed for applications requiring stable and efficient power delivery. This SOT-23-5 packaged device offers a fixed output voltage of 1.8V and a maximum output current of 150mA. Key features include a low dropout voltage of 0.1V at 150mA, a quiescent current of 550 µA, and robust protection mechanisms including over current, over temperature, short circuit, and reverse polarity protection. The regulator also incorporates an Enable pin for control and exhibits a Power Supply Rejection Ratio (PSRR) ranging from 58dB to 37dB across a 100Hz to 10kHz frequency range. Operating from an input voltage up to 5.5V, it is suitable for use in various industrial and consumer electronics, including portable devices and sensor applications. The component is supplied in a Tape & Reel (TR) package.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: DiscontinuedPackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | SC-74A, SOT-753 |
| Output Type | Fixed |
| Mounting Type | Surface Mount |
| Current - Output | 150mA |
| Operating Temperature | -40°C ~ 125°C |
| Output Configuration | Positive |
| Current - Quiescent (Iq) | 550 µA |
| Voltage - Input (Max) | 5.5V |
| Number of Regulators | 1 |
| Supplier Device Package | SOT-23-5 |
| Voltage - Output (Max) | - |
| Voltage - Output (Min/Fixed) | 1.8V |
| Control Features | Enable |
| PSRR | 58dB ~ 37dB (100Hz ~ 10kHz) |
| Voltage Dropout (Max) | 0.1V @ 150mA |
| Protection Features | Over Current, Over Temperature, Short Circuit, Reverse Polarity |
| Current - Supply (Max) | 750 µA |
