TPS72501DCQRG4
IC REG LINEAR POS ADJ 1A SOT223Manufacturer: Texas Instruments
Categories: Linear, Low Drop Out (LDO) Regulators
Quality Control: Learn More
Texas Instruments TPS72501DCQRG4 is a positive adjustable linear voltage regulator IC offering a 1A output current. This device features adjustable output voltage from 1.22V to 5.5V with a maximum input voltage of 6V. The SOT-223-6 package facilitates surface mount applications. Key control features include Enable and Reset functionalities. Protection mechanisms encompass Over Current, Over Temperature, Reverse Polarity, and Under Voltage Lockout (UVLO). Quiescent current is rated at 225 µA, with a maximum supply current of 325 µA. The dropout voltage is a low 0.28V at 1A, and the component exhibits 60dB PSRR at 1kHz. This regulator is suitable for use in industrial and automotive applications. It is supplied in Tape & Reel (TR) packaging.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | SOT-223-6 |
| Output Type | Adjustable |
| Mounting Type | Surface Mount |
| Current - Output | 1A |
| Operating Temperature | -40°C ~ 125°C |
| Output Configuration | Positive |
| Current - Quiescent (Iq) | 225 µA |
| Voltage - Input (Max) | 6V |
| Number of Regulators | 1 |
| Supplier Device Package | SOT-223-6 |
| Voltage - Output (Max) | 5.5V |
| Voltage - Output (Min/Fixed) | 1.22V |
| Control Features | Enable, Reset |
| PSRR | 60dB (1kHz) |
| Voltage Dropout (Max) | 0.28V @ 1A |
| Protection Features | Over Current, Over Temperature, Reverse Polarity, Under Voltage Lockout (UVLO) |
| Current - Supply (Max) | 325 µA |
