LP2985IM5-6.1/NOPB
IC REG LINEAR 6.1V 150MA SOT23-5Manufacturer: Texas Instruments
Categories: Linear, Low Drop Out (LDO) Regulators
Quality Control: Learn More
Texas Instruments LP2985IM5-6-1-NOPB is a linear voltage regulator with a fixed 6.1V output. This device provides a stable 150mA output current with a low quiescent current of 95µA. Designed for surface mount applications, it is supplied in a SOT-23-5 package. Key protection features include over-current, over-temperature, and short-circuit protection. The regulator offers a typical PSRR of 45dB at 1kHz and supports an input voltage range up to 16V. Dropout voltage is rated at 0.58V maximum at the full 150mA output. This component is suitable for use in battery-powered devices and portable electronics.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: 6 week(s)Product Status: ActivePackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | SC-74A, SOT-753 |
| Output Type | Fixed |
| Mounting Type | Surface Mount |
| Current - Output | 150mA |
| Operating Temperature | -40°C ~ 125°C |
| Output Configuration | Positive |
| Current - Quiescent (Iq) | 95 µA |
| Voltage - Input (Max) | 16V |
| Number of Regulators | 1 |
| Supplier Device Package | SOT-23-5 |
| Voltage - Output (Max) | - |
| Voltage - Output (Min/Fixed) | 6.1V |
| Control Features | Enable |
| PSRR | 45dB (1kHz) |
| Voltage Dropout (Max) | 0.58V @ 150mA |
| Protection Features | Over Current, Over Temperature, Short Circuit |
| Current - Supply (Max) | 2.5 mA |
