LM340K-5.0
IC REG LINEAR 5V 1.5A TO3-2Manufacturer: Texas Instruments
Categories: Linear, Low Drop Out (LDO) Regulators
Quality Control: Learn More
Texas Instruments LM340K-5-0 is a positive, fixed 5V linear voltage regulator with a 1.5A output current capability. This device offers robust protection features including over-current and short-circuit protection. It operates within a 0°C to 125°C ambient temperature range and accepts an input voltage up to 35V. The LM340K-5-0 exhibits a typical quiescent current of 6mA and a power supply rejection ratio (PSRR) of 70dB at 120Hz. The minimum input-to-output voltage differential required for regulation is 2V at a 1A load. Delivered in a TO-204AA, TO-3 package, this single-regulator IC is suitable for applications in industrial, automotive, and consumer electronics power management.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: 6 week(s)Product Status: ActivePackaging: TrayDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tray |
| Package / Case | TO-204AA, TO-3 |
| Output Type | Fixed |
| Mounting Type | Through Hole |
| Current - Output | 1.5A |
| Operating Temperature | 0°C ~ 125°C |
| Output Configuration | Positive |
| Current - Quiescent (Iq) | 6 mA |
| Voltage - Input (Max) | 35V |
| Number of Regulators | 1 |
| Supplier Device Package | TO-3-2 |
| Voltage - Output (Max) | - |
| Voltage - Output (Min/Fixed) | 5V |
| Control Features | - |
| PSRR | 70dB (120Hz) |
| Voltage Dropout (Max) | 2V @ 1A |
| Protection Features | Over Current, Short Circuit |
