LM2931IBP-3.3
IC REG LINEAR 3.3V 100MA 6USMDManufacturer: Texas Instruments
Categories: Linear, Low Drop Out (LDO) Regulators
Quality Control: Learn More
Texas Instruments LM2931IBP-3-3 is a positive fixed output linear voltage regulator. This 3.3V device delivers up to 100mA output current with a low dropout voltage of 0.3V at 100mA. It features reverse polarity, short circuit, and over-temperature protection. The device operates from an input voltage range up to 26V and exhibits a PSRR of 55dB at 120Hz. Quiescent current is 1 mA with a maximum supply current of 15 mA. The LM2931IBP-3-3 is supplied in a 6-uSMD (6-VFBGA) package, suitable for surface mounting. This component is commonly utilized in automotive, industrial, and consumer electronics applications requiring stable voltage regulation.
Additional Information
Series: -RoHS Status: RoHS non-compliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | 6-VFBGA |
| Output Type | Fixed |
| Mounting Type | Surface Mount |
| Current - Output | 100mA |
| Operating Temperature | -40°C ~ 85°C |
| Output Configuration | Positive |
| Current - Quiescent (Iq) | 1 mA |
| Voltage - Input (Max) | 26V |
| Number of Regulators | 1 |
| Supplier Device Package | 6-uSMD |
| Voltage - Output (Max) | - |
| Voltage - Output (Min/Fixed) | 3.3V |
| Control Features | - |
| PSRR | 55dB (120Hz) |
| Voltage Dropout (Max) | 0.3V @ 100mA |
| Protection Features | Over Temperature, Reverse Polarity, Short Circuit |
| Current - Supply (Max) | 15 mA |
