PDRV5053CAQLPG
SENSOR HALL EFFECT ANALOG TO92-3Manufacturer: Texas Instruments
Categories: Linear, Compass (ICs)
Quality Control: Learn More
Texas Instruments PDRV5053CAQLPG is a single-axis analog Hall effect sensor housed in a TO-92-3 package. This component is designed for applications requiring precise magnetic field detection, offering a sensing range of ±35mT. Its temperature compensated features ensure stable performance across an operating temperature range of -40°C to 125°C. The device operates with a supply voltage from 2.5V to 38V, drawing a maximum supply current of 3.6mA and providing a maximum output current of 2.3mA. With a bandwidth of 20kHz, it is suitable for a variety of industrial and automotive applications, including position sensing, speed detection, and current monitoring. The through-hole mounting type and TO-92-3 supplier device package facilitate straightforward integration into existing designs.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: BulkDatasheet:Download Free CAD Model:
Technical Details:
| Features | Temperature Compensated |
| Packaging | Bulk |
| Package / Case | TO-226-3, TO-92-3 Short Body |
| Output Type | Analog Voltage |
| Mounting Type | Through Hole |
| Axis | Single |
| Operating Temperature | -40°C ~ 125°C |
| Voltage - Supply | 2.5V ~ 38V |
| Bandwidth | 20kHz |
| Technology | Hall Effect |
| Resolution | - |
| Sensing Range | ±35mT |
| Current - Output (Max) | 2.3mA |
| Current - Supply (Max) | 3.6mA |
| Supplier Device Package | TO-92-3 |
Request a Quote
