TPS61060DRBRG4
IC LED DRVR RGLTR PWM 400MA 8SONManufacturer: Texas Instruments
Categories: LED Drivers
Quality Control: Learn More
Texas Instruments TPS61060DRBRG4 is a highly efficient DC-DC step-up (boost) regulator designed for driving LEDs. This device features a single output capable of delivering up to 400mA switch current, with a maximum output voltage of 14.5V. The TPS61060DRBRG4 integrates an internal switch and supports PWM dimming for precise brightness control, operating at a fixed frequency of 1MHz. Its topology is a step-up (boost) converter, suitable for applications requiring voltage conversion from a minimum supply of 2.7V up to a maximum of 6V.
The component is housed in an 8-SON (3x3) package with surface mount mounting type and is supplied on tape and reel. It is engineered for operation across a wide temperature range of -40°C to 85°C (TA). This LED driver IC is commonly utilized in backlight applications across various industries.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: DiscontinuedPackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | 8-VDFN Exposed Pad |
| Voltage - Output | 14.5V |
| Mounting Type | Surface Mount |
| Number of Outputs | 1 |
| Frequency | 1MHz |
| Type | DC DC Regulator |
| Operating Temperature | -40°C ~ 85°C (TA) |
| Applications | Backlight |
| Current - Output / Channel | 400mA (Switch) |
| Internal Switch(s) | Yes |
| Topology | Step-Up (Boost) |
| Supplier Device Package | 8-SON (3x3) |
| Dimming | PWM |
| Voltage - Supply (Min) | 2.7V |
| Voltage - Supply (Max) | 6V |
