LM2795BL/NOPB
IC LED DRV RGLTR PWM 14DSBGAManufacturer: Texas Instruments
Categories: LED Drivers
Quality Control: Learn More
The Texas Instruments LM2795BL-NOPB is a versatile LED driver IC. This device features a switched-capacitor (charge pump) DC-DC regulator topology, enabling efficient power conversion for LED applications. It provides four regulated outputs, each capable of delivering up to 20mA. The LM2795BL-NOPB supports both analog and PWM dimming for precise brightness control. Its internal switching capability and a nominal operating frequency of 515kHz contribute to its performance. Designed for surface mount installation, this component is housed in a compact 14-DSBGA package, supplied on tape and reel. It operates within a supply voltage range of 2.7V to 5.5V, with an output voltage of 3.8V. This LED driver finds application in backlighting systems, operating across a temperature range of -30°C to 85°C.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | 14-WFBGA, DSBGA |
| Voltage - Output | 3.8V |
| Mounting Type | Surface Mount |
| Number of Outputs | 4 |
| Frequency | 515kHz |
| Type | DC DC Regulator |
| Operating Temperature | -30°C ~ 85°C (TA) |
| Applications | Backlight |
| Current - Output / Channel | 20mA |
| Internal Switch(s) | Yes |
| Topology | Switched Capacitor (Charge Pump) |
| Supplier Device Package | 14-DSBGA |
| Dimming | Analog, PWM |
| Voltage - Supply (Min) | 2.7V |
| Voltage - Supply (Max) | 5.5V |
