TLE2021BMJG
EXCALIBUR HIGH-SPEED LOW-POWER PManufacturer: Texas Instruments
Categories: Instrumentation, Op Amps, Buffer Amps
Quality Control: Learn More
Texas Instruments TLE2021BMJG, an Excalibur™ series operational amplifier, offers a robust solution for demanding applications. This single-circuit, push-pull output amplifier features a low supply current of 200µA and a gain bandwidth product of 1.2 MHz, making it suitable for power-sensitive designs. Its high slew rate of 0.5V/µs and low input bias current of 33 nA contribute to accurate signal processing. The TLE2021BMJG operates across a wide temperature range of -55°C to 125°C and supports supply voltages from 4V to 40V. Packaged in an 8-CDIP configuration, this component is commonly utilized in industrial instrumentation and analog signal conditioning systems.
Additional Information
Series: Excalibur™RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: TubeDownload Free CAD Model:
Technical Details:
| Packaging | Tube |
| Package / Case | 8-CDIP (0.300"", 7.62mm) |
| Output Type | Push-Pull |
| Mounting Type | Through Hole |
| Amplifier Type | Standard |
| Operating Temperature | -55°C ~ 125°C |
| Current - Supply | 200µA |
| Slew Rate | 0.5V/µs |
| Gain Bandwidth Product | 1.2 MHz |
| Current - Input Bias | 33 nA |
| Voltage - Input Offset | 120 µV |
| Supplier Device Package | 8-CDIP |
| Number of Circuits | 1 |
| Current - Output / Channel | 20 mA |
| Voltage - Supply Span (Min) | 4 V |
| Voltage - Supply Span (Max) | 40 V |
