OPA2333AIDGKRG4
IC OPAMP ZERO-DRIFT 2CIRC 8VSSOPManufacturer: Texas Instruments
Categories: Instrumentation, Op Amps, Buffer Amps
Quality Control: Learn More
Texas Instruments OPA2333AIDGKRG4 is a dual-channel, zero-drift operational amplifier featuring CMOS technology. This amplifier provides rail-to-rail output capabilities and a low input bias current of 70 pA. With a quiescent current of just 17µA per channel and a gain bandwidth product of 350 kHz, it is well-suited for power-sensitive applications. The OPA2333AIDGKRG4 boasts an exceptionally low input offset voltage of 2 µV, minimizing errors in precision measurement circuits. Its high slew rate of 0.16V/µs ensures rapid signal response. The device operates across a supply voltage range of 1.8 V to 5.5 V and is specified for operation from -40°C to 125°C. The 8-VSSOP package facilitates surface mounting. This component is frequently utilized in instrumentation, sensor conditioning, and battery-powered portable devices.
Additional Information
Series: Zero-DriftRoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: DiscontinuedPackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | 8-TSSOP, 8-MSOP (0.118"", 3.00mm Width) |
| Output Type | Rail-to-Rail |
| Mounting Type | Surface Mount |
| Amplifier Type | CMOS, Zero-Drift |
| Operating Temperature | -40°C ~ 125°C |
| Current - Supply | 17µA (x2 Channels) |
| Slew Rate | 0.16V/µs |
| Gain Bandwidth Product | 350 kHz |
| Current - Input Bias | 70 pA |
| Voltage - Input Offset | 2 µV |
| Supplier Device Package | 8-VSSOP |
| Number of Circuits | 2 |
| Current - Output / Channel | 5 mA |
| Voltage - Supply Span (Min) | 1.8 V |
| Voltage - Supply Span (Max) | 5.5 V |
