LMH6643MM
IC OPAMP VFB 2 CIRCUIT 8VSSOPManufacturer: Texas Instruments
Categories: Instrumentation, Op Amps, Buffer Amps
Quality Control: Learn More
Texas Instruments LMH6643MM is a high-performance, 2-circuit voltage feedback operational amplifier from the LMH® series. Featuring rail-to-rail output, this device offers a -3dB bandwidth of 130 MHz and a slew rate of 135 V/µs, making it suitable for demanding applications. The LMH6643MM operates with a supply voltage range of 2.7 V to 12.8 V and consumes a low quiescent current of 2.7 mA per channel. Its robust design includes a current output of 75 mA and an input bias current of 1.6 µA. The 8-VSSOP package facilitates compact surface-mount designs. This component finds application in instrumentation, audio amplification, and general-purpose analog signal processing.
Additional Information
Series: LMH®RoHS Status: ROHS3 CompliantManufacturer Lead Time: 18 week(s)Product Status: Last Time BuyPackaging: Tape & Reel (TR)Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | 8-TSSOP, 8-MSOP (0.118"", 3.00mm Width) |
| Output Type | Rail-to-Rail |
| Mounting Type | Surface Mount |
| Amplifier Type | Voltage Feedback |
| Operating Temperature | -40°C ~ 85°C |
| Current - Supply | 2.7mA (x2 Channels) |
| Slew Rate | 135V/µs |
| Current - Input Bias | 1.6 µA |
| Voltage - Input Offset | 1 mV |
| Supplier Device Package | 8-VSSOP |
| Number of Circuits | 2 |
| Current - Output / Channel | 75 mA |
| -3db Bandwidth | 130 MHz |
| Voltage - Supply Span (Min) | 2.7 V |
| Voltage - Supply Span (Max) | 12.8 V |
Request a Quote
