LME49740MAX/NOPB
IC AUDIO 4 CIRCUIT 14SOICManufacturer: Texas Instruments
Categories: Instrumentation, Op Amps, Buffer Amps
Quality Control: Learn More
Texas Instruments LME49740MAX-NOPB is a quad-channel audio amplifier IC from the LME® series, available in a 14-SOIC package. This device offers a -3dB bandwidth of 10 MHz and a gain bandwidth product of 55 MHz, with a high slew rate of 20V/µs. The input bias current is a low 10 nA, and the input offset voltage is 100 µV. Each channel can deliver an output current of 26 mA, with a typical supply current of 18.5mA per channel across a supply voltage span from 5V to 34V. Designed for surface mount applications, this component is suitable for use in audio systems, professional audio equipment, and automotive audio applications. It operates within an ambient temperature range of -40°C to 85°C.
Additional Information
Series: LME®RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Tape & Reel (TR)Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | 14-SOIC (0.154"", 3.90mm Width) |
| Output Type | - |
| Mounting Type | Surface Mount |
| Amplifier Type | Audio |
| Operating Temperature | -40°C ~ 85°C |
| Current - Supply | 18.5mA (x4 Channels) |
| Slew Rate | 20V/µs |
| Gain Bandwidth Product | 55 MHz |
| Current - Input Bias | 10 nA |
| Voltage - Input Offset | 100 µV |
| Supplier Device Package | 14-SOIC |
| Number of Circuits | 4 |
| Current - Output / Channel | 26 mA |
| -3db Bandwidth | 10 MHz |
| Voltage - Supply Span (Min) | 5 V |
| Voltage - Supply Span (Max) | 34 V |
