LMC6062I MDC
IC CMOS 2 CIRCUIT DIEManufacturer: Texas Instruments
Categories: Instrumentation, Op Amps, Buffer Amps
Quality Control: Learn More
Texas Instruments LMC® series LMC6062I-MDC is a dual-channel CMOS amplifier designed for precision instrumentation applications. This die-packaged component features rail-to-rail output capability and a push-pull configuration, enabling efficient operation across a supply voltage range of 4.5V to 15.5V. With an extremely low input bias current of 0.01 pA and an input offset voltage of 100 µV, it is well-suited for high-impedance signal acquisition. The amplifier offers a gain bandwidth product of 100 kHz and a slew rate of 0.035V/µs, while consuming only 40µA (per channel) quiescent current. The LMC6062I-MDC operates within an industrial temperature range of -40°C to 85°C. Its characteristics make it valuable in areas such as medical devices, portable instrumentation, and industrial control systems.
Additional Information
Series: LMC®RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: TubeDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tube |
| Package / Case | Die |
| Output Type | Push-Pull, Rail-to-Rail |
| Mounting Type | Surface Mount |
| Amplifier Type | CMOS |
| Operating Temperature | -40°C ~ 85°C (TJ) |
| Current - Supply | 40µA (x2 Channels) |
| Slew Rate | 0.035V/µs |
| Gain Bandwidth Product | 100 kHz |
| Current - Input Bias | 0.01 pA |
| Voltage - Input Offset | 100 µV |
| Supplier Device Package | Die |
| Number of Circuits | 2 |
| Current - Output / Channel | 35 mA |
| Voltage - Supply Span (Min) | 4.5 V |
| Voltage - Supply Span (Max) | 15.5 V |
