LMC6044-MDC
IC CMOS 4 CIRCUIT DIEManufacturer: Texas Instruments
Categories: Instrumentation, Op Amps, Buffer Amps
Quality Control: Learn More
Texas Instruments LMC6044-MDC, a four-circuit CMOS operational amplifier from the LMC® series, delivers rail-to-rail output performance. This die-packaged component is designed for applications requiring low input bias current, specified at a mere 0.002 pA. Each of the four amplifier circuits features a push-pull output stage and operates with a low quiescent current of 52µA per channel. With a gain bandwidth product of 100 kHz and a slew rate of 0.02V/µs, this device is suitable for precision instrumentation and signal conditioning across a supply voltage range of 4.5V to 15.5V. Operating within a temperature range of -40°C to 85°C, the LMC6044-MDC is utilized in various industries including industrial automation, medical devices, and consumer electronics. The amplifier exhibits a typical input offset voltage of 1 mV and can source/sink up to 40 mA per channel.
Additional Information
Series: LMC®RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: BulkDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Bulk |
| Package / Case | Die |
| Output Type | Push-Pull, Rail-to-Rail |
| Mounting Type | Surface Mount |
| Amplifier Type | CMOS |
| Operating Temperature | -40°C ~ 85°C (TJ) |
| Current - Supply | 52µA (x4 Channels) |
| Slew Rate | 0.02V/µs |
| Gain Bandwidth Product | 100 kHz |
| Current - Input Bias | 0.002 pA |
| Voltage - Input Offset | 1 mV |
| Supplier Device Package | Die |
| Number of Circuits | 4 |
| Current - Output / Channel | 40 mA |
| Voltage - Supply Span (Min) | 4.5 V |
| Voltage - Supply Span (Max) | 15.5 V |
