LMC6001A MDC
IC OPAMP GP 1 CIRCUIT DIESALEManufacturer: Texas Instruments
Categories: Instrumentation, Op Amps, Buffer Amps
Quality Control: Learn More
Texas Instruments LMC6001A-MDC represents a general-purpose, single-circuit operational amplifier in a diesale package. This low-input bias current amplifier offers exceptional performance with a typical input bias current of 0.01 pA, making it suitable for high-impedance measurement applications. It features a rail-to-rail output stage and a gain bandwidth product of 1.3 MHz. With a quiescent current of 550µA and a slew rate of 1.5V/µs, the LMC6001A-MDC operates across a supply voltage range of 4.5V to 15.5V. Its robust design is evident in its operating temperature range of -40°C to 85°C. This component finds utility in instrumentation, analog signal processing, and sensor interfacing across various industrial and medical equipment sectors.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: TubeDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tube |
| Package / Case | Die |
| Output Type | Rail-to-Rail |
| Mounting Type | Surface Mount |
| Amplifier Type | General Purpose |
| Operating Temperature | -40°C ~ 85°C |
| Current - Supply | 550µA |
| Slew Rate | 1.5V/µs |
| Gain Bandwidth Product | 1.3 MHz |
| Current - Input Bias | 0.01 pA |
| Voltage - Input Offset | 350 µV |
| Supplier Device Package | Diesale |
| Number of Circuits | 1 |
| Current - Output / Channel | 34 mA |
| Voltage - Supply Span (Min) | 4.5 V |
| Voltage - Supply Span (Max) | 15.5 V |
