LM358BP
IC OPAMP GP 2 CIRCUIT 8USMDManufacturer: Texas Instruments
Categories: Instrumentation, Op Amps, Buffer Amps
Quality Control: Learn More
Texas Instruments LM358BP is a general-purpose operational amplifier featuring two independent circuits within an 8-uSMD package. This device offers a gain bandwidth product of 1.2 MHz and a slew rate of 0.5V/µs, making it suitable for a wide range of amplification tasks. With a low input bias current of 10 nA and an output current capability of 40 mA per channel, it demonstrates versatility in signal conditioning applications. The LM358BP operates across a supply voltage range of 3V to 30V, with a typical quiescent current of 300µA per channel. Its surface mount configuration, specifically the 8-VFBGA package, facilitates integration into compact electronic designs. Applications span various industries including industrial automation, consumer electronics, and medical instrumentation. The operating temperature range is -40°C to 85°C.
Additional Information
Series: -RoHS Status: RoHS non-compliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Tape & Reel (TR)Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | 8-VFBGA |
| Output Type | - |
| Mounting Type | Surface Mount |
| Amplifier Type | General Purpose |
| Operating Temperature | -40°C ~ 85°C (TA) |
| Current - Supply | 300µA (x2 Channels) |
| Slew Rate | 0.5V/µs |
| Gain Bandwidth Product | 1.2 MHz |
| Current - Input Bias | 10 nA |
| Voltage - Input Offset | 1 mV |
| Supplier Device Package | 8-uSMD |
| Number of Circuits | 2 |
| Current - Output / Channel | 40 mA |
| Voltage - Supply Span (Min) | 3 V |
| Voltage - Supply Span (Max) | 30 V |
Request a Quote
