ISO124U
IC OPAMP ISOLATION 1 CIRC 8SOICManufacturer: Texas Instruments
Categories: Instrumentation, Op Amps, Buffer Amps
Quality Control: Learn More
The Texas Instruments ISO124U is a 1-circuit isolation amplifier packaged in an 8-SOIC (Supplier Device Package) configuration. This device is designed for applications requiring high input impedance and precise signal transfer across an isolation barrier. With a -3dB bandwidth of 50 kHz and a slew rate of 2V/µs, it offers robust performance for signal conditioning in demanding environments. The current output per channel is 15 mA, and the typical supply current is 5 mA, operating with a supply span from 9 V to 36 V. The ISO124U features a surface mount type and an operating temperature range of -25°C to 85°C. It finds utility in industrial automation, medical instrumentation, and power control systems where signal integrity and safety are paramount.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: 18 week(s)Product Status: ActivePackaging: TubeDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tube |
| Package / Case | 28-SOIC (0.295"", 7.50mm Width), 8 Leads |
| Output Type | - |
| Mounting Type | Surface Mount |
| Amplifier Type | Isolation |
| Operating Temperature | -25°C ~ 85°C |
| Current - Supply | 5mA |
| Slew Rate | 2V/µs |
| Voltage - Input Offset | 20 mV |
| Supplier Device Package | 8-SOIC |
| Number of Circuits | 1 |
| Current - Output / Channel | 15 mA |
| -3db Bandwidth | 50 kHz |
| Voltage - Supply Span (Min) | 9 V |
| Voltage - Supply Span (Max) | 36 V |
