ISO124P
IC OPAMP ISOLATION 1 CIRC 8DIPManufacturer: Texas Instruments
Categories: Instrumentation, Op Amps, Buffer Amps
Quality Control: Learn More
Texas Instruments ISO124P is a single-circuit isolation amplifier designed for robust performance in demanding applications. This component features a 50 kHz -3dB bandwidth and a 2V/µs slew rate, making it suitable for accurate signal conditioning in industrial environments. With a current output of 15 mA per channel and a supply current of 5 mA, it offers efficient operation. The ISO124P utilizes through-hole mounting and is housed in a standard 8-PDIP package. Operating across a temperature range of -25°C to 85°C, it supports supply voltages from 9 V to 36 V. This isolation amplifier is commonly employed in medical equipment, industrial control systems, and test and measurement instrumentation.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: 18 week(s)Product Status: ActivePackaging: TubeDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tube |
| Package / Case | 16-DIP (0.300"", 7.62mm), 8 Leads |
| Output Type | - |
| Mounting Type | Through Hole |
| Amplifier Type | Isolation |
| Operating Temperature | -25°C ~ 85°C |
| Current - Supply | 5mA |
| Slew Rate | 2V/µs |
| Voltage - Input Offset | 20 mV |
| Supplier Device Package | 8-PDIP |
| Number of Circuits | 1 |
| Current - Output / Channel | 15 mA |
| -3db Bandwidth | 50 kHz |
| Voltage - Supply Span (Min) | 9 V |
| Voltage - Supply Span (Max) | 36 V |
