ISO122U/1K
IC OPAMP ISOLATION 1 CIRC 8SOICManufacturer: Texas Instruments
Categories: Instrumentation, Op Amps, Buffer Amps
Quality Control: Learn More
Texas Instruments ISO122U-1K is a robust isolation amplifier designed for demanding applications. This single-circuit component features a 50 kHz -3dB bandwidth and a 2V/µs slew rate, ensuring accurate signal transmission in noisy environments. Operating from a supply span of 9V to 36V, it delivers a typical output current of 15 mA with a quiescent current of 5 mA. The 8-SOIC package facilitates surface mounting, and the component operates reliably across a temperature range of -25°C to 85°C. This device is well-suited for industrial automation, medical equipment, and power monitoring systems where precise and safe signal isolation is paramount.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: 18 week(s)Product Status: ActivePackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | 28-SOIC (0.295"", 7.50mm Width), 8 Leads |
| Output Type | - |
| Mounting Type | Surface Mount |
| Amplifier Type | Isolation |
| Operating Temperature | -25°C ~ 85°C |
| Current - Supply | 5mA |
| Slew Rate | 2V/µs |
| Voltage - Input Offset | 20 mV |
| Supplier Device Package | 8-SOIC |
| Number of Circuits | 1 |
| Current - Output / Channel | 15 mA |
| -3db Bandwidth | 50 kHz |
| Voltage - Supply Span (Min) | 9 V |
| Voltage - Supply Span (Max) | 36 V |
