INA333SHKQ
IC INST AMP 1 CIRCUIT 8CFPManufacturer: Texas Instruments
Categories: Instrumentation, Op Amps, Buffer Amps
Quality Control: Learn More
Texas Instruments INA333SHKQ is a precision, low-power instrumentation amplifier. This single-circuit device features rail-to-rail output and operates from a supply voltage range of 1.8V to 5.5V. With a low input bias current of 70 pA and a typical input offset voltage of 10 µV, the INA333SHKQ is well-suited for applications requiring high accuracy. It offers a 3dB bandwidth of 150 kHz and a slew rate of 0.16V/µs, supporting a maximum output current of 55 mA. The amplifier's low quiescent current of 50 µA makes it an excellent choice for battery-powered systems. The INA333SHKQ is available in an 8-pin CFP (8-CFP) package, designed for surface mounting. Its robust operating temperature range of -55°C to 210°C makes it suitable for use in industrial, medical, and automotive sectors.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ActivePackaging: TubeDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tube |
| Package / Case | 8-CSOIC (0.220"", 5.65mm Width) |
| Output Type | Rail-to-Rail |
| Mounting Type | Surface Mount |
| Amplifier Type | Instrumentation |
| Operating Temperature | -55°C ~ 210°C |
| Current - Supply | 50µA |
| Slew Rate | 0.16V/µs |
| Current - Input Bias | 70 pA |
| Voltage - Input Offset | 10 µV |
| Supplier Device Package | 8-CFP |
| Number of Circuits | 1 |
| Current - Output / Channel | 55 mA |
| -3db Bandwidth | 150 kHz |
| Voltage - Supply Span (Min) | 1.8 V |
| Voltage - Supply Span (Max) | 5.5 V |
