INA129SHKQ
IC INST AMP 1 CIRCUIT 8CFPManufacturer: Texas Instruments
Categories: Instrumentation, Op Amps, Buffer Amps
Quality Control: Learn More
Texas Instruments INA129SHKQ is a high-precision, single-circuit instrumentation amplifier housed in an 8-pin CFP package. This device boasts a low input bias current of 2 nA and an offset voltage of 25 µV, making it suitable for demanding signal conditioning applications. With a -3dB bandwidth of 1.3 MHz and a slew rate of 4V/µs, it effectively handles dynamic signals. The INA129SHKQ operates with a supply voltage range of 4.5 V to 36 V and consumes only 700 µA of quiescent current. Its robust design extends to an operating temperature range of -55°C to 210°C, making it a reliable choice for aerospace, defense, and industrial automation systems requiring accurate amplification of low-level signals.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ActivePackaging: TubeDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tube |
| Package / Case | 8-CSOIC (0.220"", 5.65mm Width) |
| Output Type | - |
| Mounting Type | Surface Mount |
| Amplifier Type | Instrumentation |
| Operating Temperature | -55°C ~ 210°C |
| Current - Supply | 700µA |
| Slew Rate | 4V/µs |
| Current - Input Bias | 2 nA |
| Voltage - Input Offset | 25 µV |
| Supplier Device Package | 8-CFP |
| Number of Circuits | 1 |
| Current - Output / Channel | 15 mA |
| -3db Bandwidth | 1.3 MHz |
| Voltage - Supply Span (Min) | 4.5 V |
| Voltage - Supply Span (Max) | 36 V |
Request a Quote
