PCA9554PW
IC XPND 400KHZ I2C SMBUS 16TSSOPManufacturer: Texas Instruments
Categories: I/O Expanders
Quality Control: Learn More
Texas Instruments PCA9554PW is an 8-bit I/O expander designed for I2C and SMBus interfaces, operating at up to 400 kHz. This device features a Power-on Reset (POR) function and provides 8 push-pull I/O pins, each capable of sourcing 10mA and sinking 25mA. An interrupt output is included for event notification. The PCA9554PW is supplied in a 16-TSSOP package, suitable for surface mounting. It operates across a voltage range of 2.3V to 5.5V and maintains functionality within an industrial temperature range of -40°C to 85°C. This component finds application in various industrial automation, consumer electronics, and automotive control systems requiring efficient expansion of microcontroller I/O capabilities.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: BulkDatasheet:Download Free CAD Model:
Technical Details:
| Features | POR |
| Packaging | Bulk |
| Package / Case | 16-TSSOP (0.173"", 4.40mm Width) |
| Output Type | Push-Pull |
| Mounting Type | Surface Mount |
| Interface | I2C, SMBus |
| Number of I/O | 8 |
| Operating Temperature | -40°C ~ 85°C |
| Voltage - Supply | 2.3V ~ 5.5V |
| Clock Frequency | 400 kHz |
| Interrupt Output | Yes |
| Supplier Device Package | 16-TSSOP |
| Current - Output Source/Sink | 10mA, 25mA |
| Programmable | Not Verified |
