PCA9535DW
IC XPNDR 400KHZ I2C SMBUS 24SOICManufacturer: Texas Instruments
Categories: I/O Expanders
Quality Control: Learn More
I/O Expander 16 I2C, SMBus 400 kHz 24-SOIC
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: 6 week(s)Product Status: ActivePackaging: BulkDatasheet:Download Free CAD Model:
Technical Details:
| Features | POR |
| Packaging | Bulk |
| Package / Case | 24-SOIC (0.295"", 7.50mm Width) |
| Output Type | Push-Pull |
| Mounting Type | Surface Mount |
| Interface | I2C, SMBus |
| Number of I/O | 16 |
| Operating Temperature | -40°C ~ 85°C |
| Voltage - Supply | 2.3V ~ 5.5V |
| Clock Frequency | 400 kHz |
| Interrupt Output | Yes |
| Supplier Device Package | 24-SOIC |
| Current - Output Source/Sink | 10mA, 25mA |
| Programmable | Not Verified |
