UCC27324PG4
IC GATE DRVR LOW-SIDE 8DIPManufacturer: Texas Instruments
Categories: Gate Drivers
Quality Control: Learn More
Texas Instruments UCC27324PG4 is a dual-channel, low-side gate driver designed for N-channel and P-channel MOSFETs. This non-inverting driver features independent channels, each capable of delivering 4A peak output current in both source and sink configurations. The UCC27324PG4 operates with a supply voltage range of 4.5V to 15V and is suitable for applications requiring fast switching, with typical rise and fall times of 20ns and 15ns respectively. Its robust design includes input logic thresholds of 1V for VIL and 2V for VIH, facilitating compatibility with various microcontroller families. The device is housed in an 8-PDIP package, suitable for through-hole mounting and operating across a temperature range of -40°C to 125°C. This component finds application in power conversion systems, motor control, and power supply designs.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: DiscontinuedPackaging: TubeDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tube |
| Package / Case | 8-DIP (0.300"", 7.62mm) |
| Mounting Type | Through Hole |
| Operating Temperature | -40°C ~ 125°C (TJ) |
| Voltage - Supply | 4.5V ~ 15V |
| Input Type | Non-Inverting |
| Supplier Device Package | 8-PDIP |
| Rise / Fall Time (Typ) | 20ns, 15ns |
| Channel Type | Independent |
| Driven Configuration | Low-Side |
| Number of Drivers | 2 |
| Gate Type | N-Channel, P-Channel MOSFET |
| Logic Voltage - VIL, VIH | 1V, 2V |
| Current - Peak Output (Source, Sink) | 4A, 4A |
| Programmable | Not Verified |
