UCC27201ADRMT
IC GATE DRVR HALF-BRIDGE 8VSONManufacturer: Texas Instruments
Categories: Gate Drivers
Quality Control: Learn More
Texas Instruments UCC27201ADRMT is a high-speed, half-bridge gate driver designed for driving N-channel MOSFETs. This device features independent, non-inverting inputs for precise control of each half-bridge leg. It delivers robust performance with peak output currents of 3A sourcing and 3A sinking, enabling efficient switching of power MOSFETs. The UCC27201ADRMT supports a high-side voltage of up to 120V when utilizing a bootstrap capacitor, making it suitable for demanding high-voltage applications. Its 8-VSON (4x4) package with an exposed pad ensures excellent thermal management for reliable operation across an industrial temperature range of -40°C to 140°C. Typical rise and fall times of 8ns and 7ns, respectively, contribute to reduced switching losses. This component finds application in power supplies, motor control, and automotive electronics.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: 18 week(s)Product Status: Last Time BuyPackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | 8-VDFN Exposed Pad |
| Mounting Type | Surface Mount |
| Operating Temperature | -40°C ~ 140°C (TJ) |
| Voltage - Supply | 8V ~ 17V |
| Input Type | Non-Inverting |
| High Side Voltage - Max (Bootstrap) | 120 V |
| Supplier Device Package | 8-VSON (4x4) |
| Rise / Fall Time (Typ) | 8ns, 7ns |
| Channel Type | Independent |
| Driven Configuration | Half-Bridge |
| Number of Drivers | 2 |
| Gate Type | N-Channel MOSFET |
| Logic Voltage - VIL, VIH | 0.8V, 2.5V |
| Current - Peak Output (Source, Sink) | 3A, 3A |
| Programmable | Not Verified |
