UC3717ANG4
IC HALF BRIDGE DRIVER 1A 16DIPManufacturer: Texas Instruments
Categories: Full Half-Bridge (H Bridge) Drivers
Quality Control: Learn More
Texas Instruments UC3717ANG4 is a bipolar half-bridge driver designed for general-purpose applications, including stepper motor control. This component features a 1A output current capability and fault protection for over-temperature conditions. The integrated bootstrap circuit facilitates high-side driver operation. The UC3717ANG4 operates from a supply voltage range of 4.75V to 5.25V, with a load voltage capability up to 46V. Its output configuration is a half-bridge, suitable for driving inductive loads. The device is provided in a 16-PDIP (0.300", 7.62mm) through-hole mounting package. Typical industries utilizing this component include industrial automation and robotics.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: DiscontinuedPackaging: TubeDatasheet:Download Free CAD Model:
Technical Details:
| Features | Bootstrap Circuit |
| Packaging | Tube |
| Package / Case | 16-DIP (0.300"", 7.62mm) |
| Mounting Type | Through Hole |
| Interface | Logic |
| Operating Temperature | 0°C ~ 150°C (TJ) |
| Output Configuration | Half Bridge (2) |
| Voltage - Supply | 4.75V ~ 5.25V |
| Rds On (Typ) | - |
| Applications | General Purpose, Stepper Motors |
| Current - Output / Channel | 1A |
| Current - Peak Output | - |
| Technology | Bipolar |
| Voltage - Load | 10V ~ 46V |
| Supplier Device Package | 16-PDIP |
| Fault Protection | Over Temperature |
| Load Type | Inductive |
