LMG5200MOFT
IC HALF BRIDGE DRIVER 10A 9QFNManufacturer: Texas Instruments
Categories: Full Half-Bridge (H Bridge) Drivers
Quality Control: Learn More
The Texas Instruments LMG5200MOFT is a high-performance half-bridge driver designed for synchronous buck converters utilizing Gallium Nitride (GaN) FETs. This component features a bootstrap circuit for efficient high-side driving and provides 10A of output current per channel. Operating from a 4.75V to 5.25V supply, it supports inductive load types and offers fault protection through UVLO. With a low Rds(on) of 15mOhm for both low-side and high-side FETs, the LMG5200MOFT is suitable for applications demanding high efficiency and power density. Its 9-QFN (8x6) package facilitates surface mounting and operates across a temperature range of -40°C to 125°C. This driver is commonly employed in power supply designs for industrial and automotive sectors.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: 18 week(s)Product Status: ActivePackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Features | Bootstrap Circuit |
| Packaging | Tape & Reel (TR) |
| Package / Case | 9-QFN |
| Mounting Type | Surface Mount |
| Interface | Logic |
| Operating Temperature | -40°C ~ 125°C (TJ) |
| Output Configuration | Half Bridge |
| Voltage - Supply | 4.75V ~ 5.25V |
| Rds On (Typ) | 15mOhm LS, 15mOhm HS |
| Applications | Synchronous Buck Converters |
| Current - Output / Channel | 10A |
| Current - Peak Output | - |
| Technology | Gallium Nitride (GaN) FETs |
| Voltage - Load | 80V |
| Supplier Device Package | 9-QFN (8x6) |
| Fault Protection | UVLO |
| Load Type | Inductive |
