X66AK2G02ZBB60
GALILEOManufacturer: Texas Instruments
Categories: DSP (Digital Signal Processors)
Quality Control: Learn More
Texas Instruments X66AK2G02ZBB60, a member of the 66AK2G0x KeyStone II Multicore series, is a dual-core processor featuring one ARM Cortex-A15 core and one C66x DSP core, both operating at 600MHz. This device offers a robust set of peripherals including CAN, Ethernet, SPI, UART, and USB interfaces, alongside DMA and EBI/EMI for efficient data handling. With 1Mb of on-chip RAM and support for external non-volatile memory, it is well-suited for demanding applications. The 625-NFBGA (21x21) package with a 0.9V core voltage and 1.8V/3.3V I/O voltages is designed for surface mounting. This processor finds application in industrial automation, telecommunications, and imaging systems.
Additional Information
Series: 66AK2G0x KeyStone II MulticoreRoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: TrayDownload Free CAD Model:
Technical Details:
| Packaging | Tray |
| Package / Case | 625-LFBGA |
| Mounting Type | Surface Mount |
| Interface | CAN, DMA, EBI/EMI, Ethernet, I2C, McASP, McBSP, MMC/SD, QSPI, SPI, UART, USB |
| Type | DSP+ARM® |
| Operating Temperature | 0°C ~ 90°C (TJ) |
| Non-Volatile Memory | External |
| On-Chip RAM | 1Mb |
| Voltage - I/O | 1.8V, 3.3V |
| Voltage - Core | 0.9V |
| Clock Rate | 600MHz |
| Supplier Device Package | 625-NFBGA (21x21) |
