TMS320VC5506ZHH
IC FIXED-POINT DSP 179-BGAManufacturer: Texas Instruments
Categories: DSP (Digital Signal Processors)
Quality Control: Learn More
Texas Instruments TMS320VC5506ZHH is a fixed-point Digital Signal Processor (DSP) from the TMS320C55x series. This 179-BGA packaged device operates at a clock rate of 108MHz, featuring 128KB of on-chip RAM and external non-volatile memory support. Key interfaces include Host Interface, I2C, and McBSP, facilitating robust data communication. The device supports core voltages of 1.20V and I/O voltages of 3.00V and 3.30V, and is designed for surface mounting. Its operating temperature range is -40°C to 85°C. Applications for this DSP are found in areas such as industrial automation, telecommunications, and consumer electronics.
Additional Information
Series: TMS320C55xRoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: TubeDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tube |
| Package / Case | 179-LFBGA |
| Mounting Type | Surface Mount |
| Interface | Host Interface, I2C, McBSP |
| Type | Fixed Point |
| Operating Temperature | -40°C ~ 85°C (TC) |
| Non-Volatile Memory | External |
| On-Chip RAM | 128KB |
| Voltage - I/O | 3.00V, 3.30V |
| Voltage - Core | 1.20V |
| Clock Rate | 108MHz |
| Supplier Device Package | 179-BGA MicroStar (12x12) |
