SN75161BNE4
IC TRANSCEIVER HALF 8/8 20DIPManufacturer: Texas Instruments
Categories: Drivers, Receivers, Transceivers
Quality Control: Learn More
Texas Instruments SN75161BNE4 is an 8/8 transceiver designed for IEEE 488 protocol applications. This through-hole component features a half-duplex configuration with 8 drivers and 8 receivers. Operating within a voltage supply range of 4.75V to 5.25V, it offers a receiver hysteresis of 650 mV. The device is housed in a 20-PDIP package, measuring 20-DIP (0.300", 7.62mm). Its operating temperature range is 0°C to 70°C (TA). This component is commonly utilized in test and measurement equipment, industrial automation, and general-purpose data communication systems requiring adherence to the IEEE 488 standard.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: TubeDownload Free CAD Model:
Technical Details:
| Packaging | Tube |
| Package / Case | 20-DIP (0.300"", 7.62mm) |
| Mounting Type | Through Hole |
| Type | Transceiver |
| Operating Temperature | 0°C ~ 70°C (TA) |
| Voltage - Supply | 4.75V ~ 5.25V |
| Number of Drivers/Receivers | 8/8 |
| Data Rate | - |
| Protocol | IEEE 488 |
| Supplier Device Package | 20-PDIP |
| Receiver Hysteresis | 650 mV |
| Duplex | Half |
