MAX3222IDBRE4
IC TRANSCEIVER FULL 2/2 20SSOPManufacturer: Texas Instruments
Categories: Drivers, Receivers, Transceivers
Quality Control: Learn More
Texas Instruments MAX3222IDBRE4 is a 2/2 transceiver for RS232 communication, housed in a 20-SSOP package. This device supports a data rate of up to 250kbps and operates with a single power supply ranging from 3V to 5.5V. The MAX3222IDBRE4 features full duplex operation with two drivers and two receivers, ensuring robust serial data transmission. Each receiver includes 300mV of hysteresis for improved noise immunity. Mounting is via surface mount, and the component is supplied on tape and reel. This transceiver is commonly found in industrial automation, consumer electronics, and portable devices.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | 20-SSOP (0.209"", 5.30mm Width) |
| Mounting Type | Surface Mount |
| Type | Transceiver |
| Operating Temperature | -40°C ~ 85°C |
| Voltage - Supply | 3V ~ 5.5V |
| Number of Drivers/Receivers | 2/2 |
| Data Rate | 250kbps |
| Protocol | RS232 |
| Supplier Device Package | 20-SSOP |
| Receiver Hysteresis | 300 mV |
| Duplex | Full |
