GD75232PWRE4
IC TRANSCEIVER FULL 3/5 20TSSOPManufacturer: Texas Instruments
Categories: Drivers, Receivers, Transceivers
Quality Control: Learn More
Texas Instruments GD75232PWRE4 is a 3/5 transceiver conforming to the RS232 protocol. This device operates as a full-duplex transceiver, supporting a data rate of 120kbps. It is housed in a 20-TSSOP package with a 0.173" (4.40mm) width, suitable for surface mount applications. The transceiver is designed for operation across a voltage supply range of 5V, with additional support for ±7.5V to ±15V. Receiver hysteresis is rated at 500mV, contributing to robust signal reception. The GD75232PWRE4 is commonly utilized in industrial automation, telecommunications infrastructure, and consumer electronics where reliable serial communication is paramount. The component is supplied in Tape & Reel packaging.
Additional Information
Series: GDRoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | 20-TSSOP (0.173"", 4.40mm Width) |
| Mounting Type | Surface Mount |
| Type | Transceiver |
| Operating Temperature | 0°C ~ 70°C |
| Voltage - Supply | 5V, ±7.5V ~ 15V |
| Number of Drivers/Receivers | 3/5 |
| Data Rate | 120kbps |
| Protocol | RS232 |
| Supplier Device Package | 20-TSSOP |
| Receiver Hysteresis | 500 mV |
| Duplex | Full |
