DS8921AM
IC TRANSCEIVER FULL 1/1 8SOICManufacturer: Texas Instruments
Categories: Drivers, Receivers, Transceivers
Quality Control: Learn More
Texas Instruments DS8921AM is a full duplex RS422 and RS485 transceiver in an 8-SOIC package. This component features 1 driver and 1 receiver, designed for reliable serial communication. It operates from a 4.5V to 5.5V supply voltage and offers a receiver hysteresis of 70mV to enhance noise immunity. The surface mountable design and 8-SOIC package make it suitable for high-density board layouts. The DS8921AM is utilized in industrial automation, telecommunications, and general-purpose data acquisition systems requiring robust differential signaling. It is supplied in tube packaging.
Additional Information
Series: -RoHS Status: RoHS non-compliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: TubeDownload Free CAD Model:
Technical Details:
| Packaging | Tube |
| Package / Case | 8-SOIC (0.154"", 3.90mm Width) |
| Mounting Type | Surface Mount |
| Type | Transceiver |
| Operating Temperature | 0°C ~ 70°C |
| Voltage - Supply | 4.5V ~ 5.5V |
| Number of Drivers/Receivers | 1/1 |
| Data Rate | - |
| Protocol | RS422, RS485 |
| Supplier Device Package | 8-SOIC |
| Receiver Hysteresis | 70 mV |
| Duplex | Full |
