TLV5618AMFKB
IC DAC 12BIT V-OUT 20LCCCManufacturer: Texas Instruments
Categories: Digital to Analog Converters (DAC)
Quality Control: Learn More
12 Bit Digital to Analog Converter 2 20-LCCC (8.89x8.89)
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ActivePackaging: TubeDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tube |
| Package / Case | 20-CLCC |
| Output Type | Voltage - Buffered |
| Mounting Type | Surface Mount |
| Number of Bits | 12 |
| Data Interface | 3-Wire Serial, Microwire, QSPI, SPI |
| Reference Type | External |
| Operating Temperature | -55°C ~ 125°C |
| Voltage - Supply, Analog | 2.7V ~ 3.3V, 4.5V ~ 5.5V |
| Voltage - Supply, Digital | 2.7V ~ 3.3V, 4.5V ~ 5.5V |
| Settling Time | 3µs |
| Supplier Device Package | 20-LCCC (8.89x8.89) |
| Architecture | String DAC |
| Number of D/A Converters | 2 |
| INL/DNL (LSB) | ±2, ±0.5 |
| Differential Output | No |
| Programmable | Not Verified |
Request a Quote
