DAC1220EG4
IC DAC 20BIT V-OUT 16SSOPManufacturer: Texas Instruments
Categories: Digital to Analog Converters (DAC)
Quality Control: Learn More
Texas Instruments DAC1220EG4 is a 20-bit, single-channel voltage-output digital-to-analog converter. This device features a Sigma-Delta architecture and accepts a SPI data interface, making it suitable for applications requiring high precision. The unbuffered voltage output offers flexibility in system design. Operating from a 5V analog and 5V digital supply, the DAC1220EG4 is specified for an operating temperature range of -40°C to 85°C. The component is housed in a 16-SSOP package, designed for surface mounting. Its settling time is approximately 2ms. This DAC is commonly utilized in industrial automation, test and measurement equipment, and audio processing systems. The external reference type allows for precise control of the output voltage range.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: DiscontinuedPackaging: TubeDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tube |
| Package / Case | 16-SSOP (0.154"", 3.90mm Width) |
| Output Type | Voltage - Unbuffered |
| Mounting Type | Surface Mount |
| Number of Bits | 20 |
| Data Interface | SPI |
| Reference Type | External |
| Operating Temperature | -40°C ~ 85°C |
| Voltage - Supply, Analog | 5V |
| Voltage - Supply, Digital | 5V |
| Settling Time | 2ms |
| Supplier Device Package | 16-SSOP |
| Architecture | Sigma-Delta |
| Number of D/A Converters | 1 |
| INL/DNL (LSB) | - |
| Differential Output | No |
| Programmable | Not Verified |
