DAC121C085CIMM/NOPB
IC DAC 12BIT V-OUT 8VSSOPManufacturer: Texas Instruments
Categories: Digital to Analog Converters (DAC)
Quality Control: Learn More
The Texas Instruments DAC121C085CIMM-NOPB is a 12-bit, single-channel digital-to-analog converter with a voltage output. This device features an I2C data interface for efficient communication and a string DAC architecture. It offers excellent linearity, with Integral Non-Linearity (INL) and Differential Non-Linearity (DNL) of +2.2/-1.5 LSB and +0.18/-0.12 LSB respectively. The DAC121C085CIMM-NOPB operates over an analog and digital supply voltage range of 2.7V to 5.5V and has a settling time of 8.5µs. It is housed in an 8-pin VSSOP package suitable for surface mounting. This component is commonly utilized in industrial automation, consumer electronics, and test and measurement equipment. The operating temperature range is -40°C to 125°C.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: 6 week(s)Product Status: ActivePackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | 8-TSSOP, 8-MSOP (0.118"", 3.00mm Width) |
| Output Type | Voltage - Buffered |
| Mounting Type | Surface Mount |
| Number of Bits | 12 |
| Data Interface | I2C |
| Reference Type | External |
| Operating Temperature | -40°C ~ 125°C |
| Voltage - Supply, Analog | 2.7V ~ 5.5V |
| Voltage - Supply, Digital | 2.7V ~ 5.5V |
| Settling Time | 8.5µs |
| Supplier Device Package | 8-VSSOP |
| Architecture | String DAC |
| Number of D/A Converters | 1 |
| INL/DNL (LSB) | +2.2/-1.5, +0.18/-0.12 |
| Differential Output | No |
| Programmable | Not Verified |
