LM2840YMKX-ADJL/NOPB
IC REG BUCK ADJ 100MA TSOT23-6Manufacturer: Texas Instruments
Categories: DC DC Switching Regulators
Quality Control: Learn More
Texas Instruments LM2840YMKX-ADJL-NOPB is a step-down switching regulator designed for efficient power conversion. This adjustable output buck regulator operates with an input voltage range of 4.5V to 42V, providing a programmable output voltage from 0.765V up to 34V. With a maximum output current of 100mA and a switching frequency of 1.25MHz, it is suitable for applications requiring compact and precise voltage regulation. The device features a positive adjustable output configuration and a non-synchronous buck topology. Supplied in a TSOT-23-6 package, this component is ideal for surface-mount designs and is commonly utilized in industrial, medical, and consumer electronics sectors where space-constrained power management is critical.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Tape & Reel (TR)Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | SOT-23-6 Thin, TSOT-23-6 |
| Output Type | Adjustable |
| Mounting Type | Surface Mount |
| Number of Outputs | 1 |
| Function | Step-Down |
| Current - Output | 100mA |
| Operating Temperature | -40°C ~ 125°C (TJ) |
| Output Configuration | Positive |
| Frequency - Switching | 1.25MHz |
| Voltage - Input (Max) | 42V |
| Topology | Buck |
| Supplier Device Package | TSOT-23-6 |
| Synchronous Rectifier | No |
| Voltage - Output (Max) | 34V |
| Voltage - Input (Min) | 4.5V |
| Voltage - Output (Min/Fixed) | 0.765V |
Request a Quote
