LM2679SD-ADJ
IC REG BUCK ADJ 5A 14VSONManufacturer: Texas Instruments
Categories: DC DC Switching Regulators
Quality Control: Learn More
The Texas Instruments LM2679SD-ADJ is a high-efficiency, 260kHz SIMPLE SWITCHER® buck regulator. This adjustable output voltage device is capable of delivering up to 5A of output current. It features a minimum input voltage of 8V and a maximum input voltage of 40V, with an adjustable output voltage ranging from 1.21V to 37V. The LM2679SD-ADJ employs a non-synchronous buck topology and is housed in a 14-VSON (5x6) package suitable for surface mounting. Operating across a temperature range of -40°C to 125°C (TJ), this component is well-suited for applications in consumer electronics, industrial automation, and power management systems. The package is supplied on Tape & Reel (TR).
Additional Information
Series: SIMPLE SWITCHER®RoHS Status: RoHS non-compliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Tape & Reel (TR)Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | 14-VDFN Exposed Pad |
| Output Type | Adjustable |
| Mounting Type | Surface Mount |
| Number of Outputs | 1 |
| Function | Step-Down |
| Current - Output | 5A |
| Operating Temperature | -40°C ~ 125°C (TJ) |
| Output Configuration | Positive |
| Frequency - Switching | 260kHz |
| Voltage - Input (Max) | 40V |
| Topology | Buck |
| Supplier Device Package | 14-VSON (5x6) |
| Synchronous Rectifier | No |
| Voltage - Output (Max) | 37V |
| Voltage - Input (Min) | 8V |
| Voltage - Output (Min/Fixed) | 1.21V |
Request a Quote
