LM2574M-5.0
IC REG BUCK 5V 500MA 14SOICManufacturer: Texas Instruments
Categories: DC DC Switching Regulators
Quality Control: Learn More
Texas Instruments SIMPLE SWITCHER® LM2574M-5-0 is a 5V positive fixed output voltage, 500mA buck switching regulator IC. This device features a 52kHz switching frequency and a non-synchronous rectifier topology. Designed for surface mount applications, it is available in a 14-SOIC package with a width of 7.50mm. The input voltage range is 4V to 40V. This component is commonly utilized in industrial automation, consumer electronics, and medical equipment.
Additional Information
Series: SIMPLE SWITCHER®RoHS Status: ROHS3 CompliantManufacturer Lead Time: 18 week(s)Product Status: Last Time BuyPackaging: TubeDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tube |
| Package / Case | 14-SOIC (0.295"", 7.50mm Width) |
| Output Type | Fixed |
| Mounting Type | Surface Mount |
| Number of Outputs | 1 |
| Function | Step-Down |
| Current - Output | 500mA |
| Operating Temperature | -40°C ~ 125°C (TJ) |
| Output Configuration | Positive |
| Frequency - Switching | 52kHz |
| Voltage - Input (Max) | 40V |
| Topology | Buck |
| Supplier Device Package | 14-SOIC |
| Synchronous Rectifier | No |
| Voltage - Output (Max) | - |
| Voltage - Input (Min) | 4V |
| Voltage - Output (Min/Fixed) | 5V |
