UCC28C55QDRQ1
AUTOMOTIVE, 30-V, LOW-POWER CURRManufacturer: Texas Instruments
Categories: DC DC Switching Controllers
Quality Control: Learn More
Buck, Boost, Flyback, Forward Converter, SEPIC Regulator Positive Output Step-Up, Step-Down, Step-Up/Step-Down DC-DC Controller IC 8-SOIC
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: 6 week(s)Product Status: ActivePackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | 8-SOIC (0.154"", 3.90mm Width) |
| Output Type | Transistor Driver |
| Mounting Type | Surface Mount |
| Function | Step-Up, Step-Down, Step-Up/Step-Down |
| Operating Temperature | -40°C ~ 150°C (TJ) |
| Output Configuration | Positive |
| Frequency - Switching | 1MHz |
| Topology | Buck, Boost, Flyback, Forward Converter, SEPIC |
| Voltage - Supply (Vcc/Vdd) | 28V |
| Supplier Device Package | 8-SOIC |
| Synchronous Rectifier | No |
| Control Features | Current Limit, Dead Time Control, Enable, Frequency Control, Soft Start |
| Serial Interfaces | - |
| Output Phases | 1 |
| Duty Cycle (Max) | 50% |
| Clock Sync | Yes |
| Grade | Automotive |
| Number of Outputs | 1 |
| Qualification | AEC-Q100 |
