UCC2813D-0
IC REG CTRLR MULT TOPOLOGY 8SOICManufacturer: Texas Instruments
Categories: DC DC Switching Controllers
Quality Control: Learn More
The Texas Instruments UCC2813D-0 is a versatile DC/DC controller IC designed for multiple switching topologies, including Boost, Flyback, and Forward converters. This 8-SOIC packaged device is engineered for positive output voltage regulation, supporting both step-up and step-up/step-down configurations. Key control features include frequency control, with a maximum duty cycle of 99%. It operates within a supply voltage range of 6.9V to 12V and is rated for an operating temperature range of -40°C to 85°C. The UCC2813D-0 is suitable for applications requiring efficient power conversion in various industries.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: TubeDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tube |
| Package / Case | 8-SOIC (0.154"", 3.90mm Width) |
| Output Type | Transistor Driver |
| Mounting Type | Surface Mount |
| Function | Step-Up, Step-Up/Step-Down |
| Operating Temperature | -40°C ~ 85°C (TA) |
| Output Configuration | Positive |
| Frequency - Switching | - |
| Topology | Boost, Flyback, Forward Converter |
| Voltage - Supply (Vcc/Vdd) | 6.9V ~ 12V |
| Supplier Device Package | 8-SOIC |
| Synchronous Rectifier | No |
| Control Features | Frequency Control |
| Serial Interfaces | - |
| Output Phases | 1 |
| Duty Cycle (Max) | 99% |
| Clock Sync | No |
| Number of Outputs | 1 |
